VSHOW Led Hybrid Moving Head S712 450W 3IN1 Led Light With CMY CTO

S712 is a 3-in-1 computer moving head light, featuring a single 450W LED light engine that integrates beam, pattern, and coloring in one unit. It is energy-efficient, with an extended lifespan, rapid heat dissipation, powerful functionality, and easy control.

Brand Name

VSHOW

Input Voltage

100-240V, 50/60Hz

Power consumption

480W

Power supply

600W

Light source

450W module LED engine

Place of Original

Guangdong, China

After-Sales Service and Warranty:

We offer comprehensive after-sales services, including installation guidance and technical support. Our products also come with a specified warranty period to ensure a worry-free experience for our customers.

Buyer Protection: We Keep Buyer Information Completely Confidential!

INQUIRY NOW

Function description

The fixed and rotating pattern discs, under the zoom lens, can project pattern effects from multiple angles. The beam angle can be adjusted through the zoom lens for enhanced flexibility. With the addition of a bi-directional rotating eight-prism, a six-row prism, double prism stacking, independent atomization effects, and electric focus, coupled with a linear CMY color mixing system, it provides rich and saturated light colors.

This is a high-performance moving head pattern light, meeting various coloring needs for different occasions. It is well-suited for entertainment venues such as bars, dance halls, nightclubs, and performances.

Parameters

Input Voltage	100-240V, 50/60Hz	Color temperature	8500K	High	90CRI
Power supply	600W	Diameter of optic lens	148mm	DMX Channel	29CH
Power consumption	480W	Beam angle	3-50°	Four dimming curves	Linear,Square law,Inverse squared law,S curve
Light source	450W module LED engine	Standard	70CRI	Operate mode	DMX512, Auto, master/slave, RDM
Color wheel	1 color wheel, 7fixed colors, plus white	Static gobo	12 gobos plus 1 white circle	Rotation Gobo	7 Gobo plus 1 white circle
Prism	Equipped with 8 prisms and 6 rows of prisms, the two prisms	High brightness frost sheet	With smooth wash effect	Fixture size	338254621mm
Net weight	20.5KG	Linear CTO color temperature adjustment	8500K–2800K

Details & Features

Excellent color mixing effect

• can be stacked and rotated in both

• CMY color macro function

• Linear CMY color mixing

Download

S712PDF

S712 KUAN

USER MANUAL

MA

Download

MA

D4

Download

D4
