VSHOW S712 Kuan Hybrid CMY & CTO Beam Spot Wash 3in1 Moving Head Lights

2023-10-23

Welcome to VSHOW's blog! Today, we spotlight the V-Show S712 Kuan Hybrid Moving Head Lights, featuring CMY & CTO capabilities for versatile beam, spot, and wash effects. Dive into our article to discover how these innovative fixtures elevate stage lighting with their dynamic features and expert control options.

40731edfd186d24fd969be1dd456bd02

Product Features:

1. Integrating beam, pattern, and dyeing functions to inspire more creativity

inspiration for you.

2. With linear CMY color mixing system and linear color temperature

adjustment of 8500-2800K .

3. 0-100% 16Bit smooth dimming,Four dimming curves .

4. Overheating self-energy protection can extending lamp life .

5. Three phase Motor with SY Brand ( XY axis magnetic coding positioning is

more accurate) .

6. two angle lens 6 ° and 35 ° can change the gobo size .

7. High quality LCD touch screen

8. Power in & Out connector,3 or 5pin XLR inout & output can optional

9. Folding clamp can optional

10. Housing material: PA6 Nylon( Solid,high temperature resistance up to 200 ° flame retardance)

Product Specification:

Input Voltage: 100-240V, 50/60Hz

Power consumption: 480W

Power supply: 600W

Light source: 450W module LED engine (21-24V,8A)

LED expected service life: 20000 hours

LED temperature: 8500K

Diameter of optic lens: 148mm

Beam angle: 3-40 °

Standard:70CRI

high :90CRI

DMX Channel: 29CH

Electric focusing system

Four dimming curves ： Linear,Square law,Inverse squared law,S curve

Operate mode: DMX512, Auto, master/slave, RDM

0-100% 16bit linear smooth dimming

Multiple speed strobe effects

CMY color macro function

Linear CMY colour mixing

Linear CTO color temperature adjustment: 8500K-2800K

Color wheel: 1 color wheel, 7fixed colors plus white

Static gobo: 12 gobos plus 1 white circle

Rotation Gobo: 7 Gobo plus 1 white circle

Prism: Equipped with 8 prism, and 6 rows prism, the two prisms

can be stacked and rotated in both

High brightness frost sheet: with smooth wash effect

Control panel: LCD Touch screen Overheating self-energy protection LED,

extending LED life

X-axis rotation angle: 540 °

Y-axis rotation angle: 270 °

Three phase motor with SY Brand

XY axis magnetic coding positioning is more accurate

Power Outlet: Power Connector Input/Output

Signal Line: 3-pin or 5-pin signal line

Installation: folding clamp

Fixture size: 338*254*621mm

Product Detail:

Product Size:

Product Effect :
